- [Waterproof]The reader design with IP68 waterproof grade,can be used indoor or outdoor
- [Card Reader Only] The reader can’t work stand-alone,have to work with access control panel or access controller
- [Card Support Frequency] The reader of this link support 13.56MHz MF/IC RFID Card,please choose the one you need
- [LED Indicator]The reader have 2 color LED Indicators(red and green)
- [Warranty]36 months warranty,if you have any question,please feel free to contact us
Note:
Please notice that our wiegand 26/34 reader can't be compatible with some encrypted cards.
Such as HID, Indala, Cobra, APCiK, Paradox, Radio, Honeywell, etc. Can't work alone, need work with access control panel or access controller. On the Active mode, when swipe the card on the reader,the card number can be uploaded to the software of Access control system automatically.
Feature:
Less than 0.2 second Response Speed
Less than 0.5 seconds Proximity Time
Built-in Antenna
Built-in LED (Double Color LED)
Built-in Loud Speaker (Buzzer)
100 Meters Communication Distance
Real Time Data Transfer
Sound & Light Indication,stable quality,with ability of anti metal disturbance
With Protection function for upper voltage and wrong wire connection
International interface: Standard is Wiegand26bits / Wiegand34bits
Specification:
Color: Black
Waterproof Degree: IP68
Material: PVC Case (Black Resin for Water-Proof Function)
Size: 110*52*22 mm/4.33*2.05*0.87 inch
Working Voltage: DC 9V-12V
Static Current: ≤ 30mA
Reading Range: EM≤12CM, MF≤8CM
Card Type: 125KHz EM-ID;13.56MHz MF Card, 15693 card and 14443A, 14443B etc.
Ambient Temperature: - 20℃ ~ 70℃/-4℉~158℉
Ambient Humidity: 10% ~ 90%
International Standard: Wiegand26bits/34bits Interface
Communication distance: WG26/34≤100m
Packing Details:
User Manual: 1 piece
RFID Card Reader: 1 piece
